Biohort Neo Aluminium Floor Panels

The aluminium floor plate for the Neo shed is the perfect solution for those seeking durability, functionality, and an elegant design. Made from high-quality 2 mm aluminium sheet, this plate provides a robust and secure base for your shed, ensuring strength and longevity.

Main Features

• Premium material: 2 mm aluminium sheet that ensures maximum stability and corrosion resistance.
• Adaptable segments: The floor consists of 3 to 5 segments, depending on the size of the shed, and includes connection profiles for easy and efficient assembly.
• Structural requirement: The aluminium floor frame is essential to ensure a perfect fit and optimal installation.
• Compatibility with underlay: It is recommended to use a filler or XPS rigid foam panels of 2 to 3 cm thickness (not included) as a base to provide additional support.

Advantages

• Easy installation: Designed to integrate perfectly with the aluminium floor frame.
• Versatility: Available in various sizes and weights to fit different Neo shed models.
• Aesthetic and functional: Combines a modern design with a wear-resistant surface, ideal for any environment.

Specifications by Size

• 1A: 157.5 x 157.5 cm, 20.3 kg
• 1B, 2A: 213 x 157.5 cm, 25 kg
• 1C, 3A: 269.5 x 157.5 cm, 32 kg
• 1D, 4A: 325.5 x 157.5 cm, 37.8 kg
• 2B: 213 x 213 cm, 34 kg
• 2C, 3B: 269.5 x 213.5 cm, 39.5 kg
• 2D, 4B: 325.5 x 213.5 cm, 47.4 kg
• 3C: 269.5 x 269.5 cm, 56 kg
• 3D, 4C: 325.5 x 269.5 cm, 66 kg
• 4D: 325.5 x 325.5 cm, 77.4 kg

Important Note

The aluminium floor frame and the filler or XPS panels are not included in the delivery volume and must be purchased separately. Enhance the stability and functionality of your Neo shed with this aluminium floor plate designed to provide a solid, durable, and aesthetically pleasing base.
